ShippingConventional Magnetic Recording
CMR
How non-shingled tracks affect updates, and what the CMR label leaves unspecified.
Glossary entry on hesela.dev · JSON record · Longitudinal recording · Adjacent-track interference and refresh
Related
On this page6 sections
In one minute
Conventional magnetic recording (CMR) is an HDD track layout without intentional shingled overlap, allowing sector updates without SMR's overlap-driven rewrite dependency.
CMR keeps recording tracks from intentionally overlapping. It avoids the physical dependency in SMR where changing data can require preserving and rewriting overlapping tracks. This describes a capability, not a promise that every host write becomes an immediate physical in-place overwrite. [8]
Do not confuse a recording mechanism with the commands a host can issue. A drive-managed SMR disk can accept ordinary random writes and handle the shingled constraint internally; host-managed SMR exposes sequential-write-required zones. SNIA's tutorial also distinguishes physical bands from logical zones and describes aggregating several cached commands before a band update. [10]
Skylight (FAST 2015) examined two Seagate drive-managed SMR models using controlled I/O and camera observations of head motion, after validating its method on three emulated drives. The tested devices accepted random writes into persistent disk caches and later cleaned data into bands. This is direct evidence that a conventional-looking host interface can conceal shingled placement, not a universal performance model for current drives. [1]
The PMR/longitudinal distinction concerns magnetization direction: perpendicular to the surface versus along the track. CMR/SMR describes overlap instead. The change from longitudinal recording to PMR therefore does not make CMR the successor to longitudinal recording. [9] [8]
Heat assistance is another property. Seagate's recording-technology list includes Mozaic HAMR CMR, illustrating that HAMR and CMR can coexist. Verify the model and its documentation rather than inferring recording layout from capacity or product-family name alone. [4]
Independently writable tracks are not magnetically isolated. Seagate describes repeated-write disturbance and protective refresh in both CMR and SMR. Western Digital's OptiNAND brief describes finer-grained write tracking used to refresh affected sectors. Those implementation examples do not establish a universal refresh threshold or an end-to-end latency guarantee. [2] [3]
Recording labels
Use recording layout to reason about overlap-driven update work; use the interface and model documentation to establish the host contract. A random-write-capable block interface is not proof of CMR. [10]
Interpret a drive description one property at a time
- CMR / SMR
- What it establishesNon-shingled / overlapping recording tracks. [8]
- What it leaves openThe direction of magnetization.
- PMR / longitudinal
- What it establishesPerpendicular / in-plane magnetization. [9]
- What it leaves openWhether tracks overlap.
- HAMR CMR
- What it establishesHeat assistance together with non-shingled layout. [4]
- What it leaves openA guaranteed workload latency or failure rate.
Uncertainty notes
- Source review, not a new benchmark or failure-rate study. No class-wide NAS, RAID or backplane compatibility is inferred from CMR.
- The SNIA 2014 tutorial supports mechanism distinctions; its draft-standard details are not presented as current command requirements.
